    Ferrite magnet 15'' 20khz Coaxial PA Speaker With Big Horn

    Ask Lasest Price
    Brand Name : OEM
    Model Number : HYW-1575-076
    Supply Ability : 50000 Piece/Pieces per Month
    Price : $50.00 - $70.00 / Piece
    • Product Details
    • Company Profile

    Ferrite magnet 15'' 20khz Coaxial PA Speaker With Big Horn


    Product Description

    Features:

    • 15“ Coaxial speaker with big horn for high sensitivity design
    • 500Wrms power handling, 1000W max power
    • 41hz- 20kHz frequency response
    • 100dB sensitivity
    • Single ferrite magnet assembly
    • Inside/Outside copper voice coil

    Specification
    Nominal diameter
    380/15
    mm/inch
    Nominal impedance
    8
    ohm
    Min impedance LF
    5.2
    ohm
    Min impedance HF
    6
    ohm
    Frequency response
    40-20k
    Hz
    RMS Power
    500
    Magnet material
    Ferrite
    Specification LF
    Sensitivity (1w/1m)
    100
    dB
    Nominal power handling
    500
    Watts
    Continuous power handling
    1000
    Watts
    Voice coil diameter
    75/3
    mm/ inch
    Winding material
    Copper
    Cone material
    Paper
    Surround material
    Cloth
    Specification HF
    Sensitivity (1w/1m)
    110
    dB
    Nominal power handling
    100
    Watts
    Continuous power handling
    200
    Watts
    Voice coil diameter
    75/3
    mm/inch
    Diaphragm
    Titanium
    T/S Parameter
    Fs
    45
    Hz
    Re
    5.2
    Qes
    0.66
    Qts
    0.60
    Qms
    6.58
    Vas
    123.7
    L
    Rms
    4.1
    kg/s
    Cms
    0.1287
    mm/N
    Mms
    94.65
    gr
    BL
    14.58
    N/A
    Mounting information
    Overall diameter
    395/15.5
    mm/inch
    Bolt Circle diameter
    375/14.76
    mm/inch
    Baffle Cutout diameter
    360/14
    mm/inch
    Total Depth
    210/8.26
    mm/inch
    Shipping information
    Net weight
    9.2
    KG
    Shipping weight
    9.7
    KG
    Shipping box
    420x420x220
    mm
