Specification
Nominal diameter	260/10	mm/inch
Nominal impedance	8	ohm
Min impedance	5.2	ohm
Frequency response	65-3k	Hz
Magnet material	Neodymium
Sensitivity (1w/1m)	97	dB
RMS power handling	450	Watts
Continuous power handling	900	Watts
Voice coil diameter	75/3	mm/ inch
Winding material	Copper
Cone material	Carbon
Surround material	Cloth
T/S Parameter
Fs	63	Hz
Re	5.2	Ω
Qes	0.29
Qts	0.28
Qms	6.3
Vas	27.68	L
Cms	0.15	mm/N
Mms	42	gr
BL	17.1	N/A
Xmax	6	mm
Mounting information
Overall diameter	260	mm/inch
Bolt Circle diameter	244.5	mm/inch
Baffle Cutout diameter	231	mm/inch
Depth	126	mm/inch
Shipping information
Net weight	4.7	KG
Shipping weight	5.5	KG
Shipping box	240x240x130	mm

Product Description

Company Profile

Since our establishment in 2009, we have been committed to manufacturing high-quality audio products, including professional audio speakers, car audio speakers, speakers with cabinets and power amplifiers. Since then, Huiyin Audio Co., Ltd. has had a complete high-quality supply chain, an excellent management team, and the ability to provide our customers with good service and high-quality products at a good price! Instead, the company introduced a series of advanced equipment such as automated production lines, high-efficiency magnetizers, impact testing machines, and temperature testing machines. To maximize, we obtained CE certification in 2012. The enterprise will be gradually developed in 2017.

We are willing to customize the speakers and amplifiers required by customers to suit their market. OEM and ODM orders are welcome.
Committed to strict quality control and thoughtful customer service, our experienced staff are always available to discuss your requirements and ensure complete customer satisfaction. When we cooperate with well-known Chinese brands, our products are also exported to customers in North America, South America, Europe, Asia, Africa and Africa and Oceania and other countries and regions. Whether it is selecting the current product from our catalog or seeking the help of an engineer to manufacture other ideal speaker models, please contact our customer service center or send an email to us. We want to establish a long-term business relationship with you.
