Top quality 15 inch monitor speaker pro audio loudspeaker LA15M

Product Description

15 inch coaxial speaker

Top quality coaxial speaker

Carbon cone
Neodymium magnet
3 inch voice coil both for LF and HF

Specification

Model No.	LA3212	LA221B	LA15M
Size	12 inch	21 inch	15 inch
Product name	Double 12 inch line array speaker	Double 21 inch subwoofer	15 inch monitor coaxial speaker
Impedance (Ω)	LF: 8Ω, Mid : 8Ω, HF : 16Ω	8	16
Frequency response	60hz-18khz	26hz-120hz(-10dB)	45hz-20khz(-10dB)
Speaker driver	LF: 2x12 inch with 3 inch voice coil, neo magnet and carbon cone HF : 2x1.5 inch HF driver with neodymium magnet and 3 inch voice coil Mid : 4x6.5 inch neo midrange speaker with carbon cone	2x21 inch subwoofer with 6 inch voice coil	1x15 inch coaxial speakers with neodymium magnet and carbon cone .
AES power handling	HF: 160W , LF: 800W , Mid: 480W	3000W	500W
Sensitivity (1w/1m)	HF:107dB, MID :100dB , LF:98dB	100dB	100dB
Box material	Wood	Wood	Wood
SPL	LF:130dB HF: 136dB	134dB(Con)/140dB(Peak)	127dB(Con)/133dB(Peak)
Nominal coverage angle	100°x10°		90°x60°
Dimension	1105x597x383mm	1400x900x600mm	540x565x374mm
Net weight	65 kg	108 kg	19.7 kg
Gross weight	70kg	113kg	23kg

Feature :

1. LA15M is top end monitor speaker for line array speaker system 2.One piece of 15 inch coaxial speaker driver with carbon cone and neo magnet 3. SPL: 127dB/133dB 4. 500W RMS power handling, 1500W max power handling 5. Working together with double 21 inch subwoofer(LA221B) and 12 inch line array speaker(LA3212) to get the perfect sound syatem.
