    6.5 inch Professional speaker loudspeaker coaxial speaker 6.5"

    Ask Lasest Price
    Brand Name : HYYX
    Model Number : HYW-650-010
    Supply Ability : 5000 Piece/Pieces per Week
    Price : $15.00 - $55.00 / Piece
    • Product Details
    • Company Profile

    6.5 inch Professional speaker loudspeaker coaxial speaker 6.5"

    Product Description
    6.5 inch Professional speaker loudspeaker coaxial speaker 6.5"
    6.5 inch Professional speaker loudspeaker coaxial speaker 6.5"


    Features :


    - 300W continuous program power capacity
    - 94dB sensitivity
    - 80hz-18khz Frequency response
    - Single magnet design
    - Titanium / Polyester diaphragm for HF driver

    - 25mm(1") HF throat size
    - 2" LF VC + 1.7" HF VC
    - Replacement diaphragm for HF , Titanium or Polyester
    Speccification :
    Specification
    Nominal diameter
    170/6.5
    mm/inch
    Nominal impedance
    8
    ohm
    Min impedance LF
    5.2
    ohm
    Min impedance HF
    6
    ohm
    Frequency response
    80-18k
    Hz
    Dispersion angle
    70
    °
    Magnet size
    145x25
    mm
    Magnet material
    Ferrite
    Specification LF
    Sensitivity (1w/1m)
    94
    dB
    Nominal power handling
    150
    Watts
    Continuous power handling
    300
    Watts
    Voice coil diameter
    50/2 "
    mm/ inch
    Winding material
    Copper
    Cone material
    Paper
    Surround material
    Cloth
    Specification HF
    Throat size
    25/1
    mm/inch
    Sensitivity (1w/1m)
    106
    dB
    Nominal power handling
    50
    Watts
    Continuous power handling
    100
    Watts
    Voice coil diameter
    44/1.7
    mm/inch
    Diaphragm
    Titanium / Polyester
    T/S Parameter
    Fs
    82.5
    Hz
    Re
    5.2
    Ω
    Qes
    0.78
    Qts
    0.74
    Qms
    15.24
    Vas
    8.8
    L
    Rms
    0.4
    kg/s
    Cms
    0.31
    mm/N
    Mms
    12.1
    gr
    BI
    6.5
    N/A
    Rp
    70.0
    Ω
    Lp
    13.3
    mH
    Cp
    508.7
    uF
    Le
    0.5
    mH
    Xmax
    6.5
    mm
    Mounting information
    Overall diameter (Diagonal)
    185/7.28
    mm/inch
    Bolt Circle diameter
    170/6.7
    mm/inch
    Baffle Cutout diameter
    147/5.78
    mm/inch
    Depth
    114/4.48
    mm/inch
    Flange thickness
    9/0.35
    mm/inch
    Shipping information
    Net weight
    2.8
    KG
    Shipping weight
    3.3
    KG
    Shipping box
    190x190x145
    mm
